Compared with the ordinary watering truck, the biggest advantage of CHD5181TDYDFE6 spray truck is its full function. It has not only the function of sprinkling and watering the roadside green belt, but also the function of spray and dust control, air quality improvement and emergency fire fighting. The truck also has self-priming function and can be absorbed by self – sucking pump. Therefore, the truck can be widely used in high grade highway, municipal and sanitation management departments.
Compared with the ordinary watering truck, the biggest advantage of CHD5181TDYDFE6 spray truck is its full function. It has not only the function of sprinkling and watering the roadside green belt, but also the function of spray and dust control, air quality improvement and emergency fire fighting. The truck also has self-priming function and can be absorbed by self – sucking pump. Therefore, the truck can be widely used in high grade highway, municipal and sanitation management departments.
Features :
| Items | Data |
| Chassis model | EQ1185LJ9CDE |
| Engine model | B6.2NS6B210 |
| Rated power | 202kW |
| Diesel generator power | 100kW |
| Dimension | 10110 mm * 2490 mm * 3920 mm |
| Wheelbase | 5300 mm |
| Max total mass | 18000 kg |
| Water container volume | 9.8 m³ |
| Sprinkler spraying range | Level: 100 m; Vertical 35-40m |
| Sprinkler spraying pressure | 1.5 – 3.5 Mpa |
| Sprinkler spraying water flow | 8 M³/h |
| Spray pitch angle | -10°/－40° |
| Horizontal rotation angle of sprinkler | 0°-320° |
| Operating efficiency | 200000-240000 m²/h |
| Low pressure watering flow | 500-800 L/min |
| Low pressure watering width | ≥24 m |
| Watering range | 38 m |
